Classification:
Rivetless machine can fully replace of punch joint to the metal sheet. The rivetless riveting process are extensively used in automobile, light work, precise machine, electric appliances and hardware etc: such as the top-window of car,
Contact:
PRODUCTS
Details Introduction
Characteristics:
● Processed point firmly
● Joint 2 pieces of metal sheet without rivet
● Protect surface plating and painting available
● Forming rond or rectangle shape available
● Processed area has no stress
● Allowed to have mezzanine and multi-layer conjunction
● Copper , aluminums, steel, zinc are all unlimited
● Equipped with pre-pressure device，overcoming distort badly.
● Desktop, vertical and cantilever style as optional
Specification of model: WMZ-8
| Max. pressure | 80Kn |
| Stroke | 75mm |
| Compulsive stroke | 5mm |
| Frequency/Min | 14-25 |
| Thickness/Galvanized sheet | 3mm (Max.) |
| Throat depth | 200mm |
| Power | 0.06Kw |
| Rated air consumption | 0.06M³/Min |
| Air source | 5-6kgf/cm² |
| Pressure adjusting | Stepless |
| Aerial lubrication | Yes |
| Physical size | 650mm x 450mm x 1600mm |
| Net weight | 240Kg |
Specification of model:WMZ-10
| Max. pressure | 100Kn |
| Stroke | 75mm |
| Compulsive stroke | 5mm |
| Frequency/Min | 14-25 |
| Thickness/Galvanized sheet | 4 mm (Max.) |
| Throat depth | 200mm |
| Power | 0.06Kw |
| Rated air consumption | 0.06M³/Min |
| Air source | 5-6kgf/cm² |
| Pressure adjusting | Stepless |
| Aerial lubrication | Yes |
| Physical size | 800mm x 380mm x 900mm |
| Net weight | 280Kg |
